Sunlight-readable LCDs up to 1500 nits with NVIS filtering, optical bonding, touch integration, and ruggedized assembly support.
Overview
Polytronix designs and manufactures custom display assemblies for aerospace, defense, industrial, medical, and simulation applications requiring ruggedized performance, high optical clarity, and reliable operation in demanding environments. Our display capabilities support standalone LCD modules, integrated display head assemblies, bezel-integrated systems, touchscreen interfaces, and fully integrated operator-display platforms.
We manufacture display assemblies from 3.5” to 15”+ diagonal formats with support for sunlight-readable LCDs up to 1500 nits, NVIS-compatible filtering, optical bonding, touchscreen integration, EMI shielding, and custom enclosure integration. Assemblies are configured to customer mechanical, electrical, environmental, and interface requirements for both retrofit and new-production programs.
Our engineering and manufacturing teams support complete integration of LCD modules, LED backlighting, driver boards, touchscreens, display controllers, heaters, filters, cable assemblies, and mounting hardware into ruggedized assemblies designed for aerospace and industrial operating environments. Depending on customer requirements, systems can incorporate resistive or capacitive touch technologies, custom video interfaces, embedded processing, signal conditioning, thermal-management systems, and environmental sealing features.
Polytronix supports display integration for cockpit systems, mission consoles, ground-support equipment, simulators, industrial operator interfaces, and custom electro-mechanical platforms. Manufacturing processes support ruggedization, vibration resistance, wide-temperature operation, and long-life display performance for mission-critical applications.
At a Glance
| Certifications | AS9100D, ISO 9001, ITAR |
|---|---|
| Program Fit | Aerospace, Defense, Industrial, Medical, Simulation |
| Core Strengths | Sunlight Readable, NVIS, Optical Bonding |
| Typical Deliverables | Display Assemblies, Display Head Systems |
| Order Quantities | Prototypes to Production Runs |
Display Types
- Sunlight-readable LCD displays
- NVIS-compatible cockpit displays
- Display head assemblies
- Integrated touchscreen displays
- Mission-console displays
- Industrial operator displays
- Panel-mounted displays
- Chassis-mounted displays
- Multi-function displays
- Secondary flight displays
- Ground-support equipment displays
- Simulation and training displays
- Custom TFT-LCD assemblies
- Ruggedized display systems
Technologies & Product Families
Passive-matrix LCD
- TN — Twisted Nematic; cost-effective, fast response, monochrome
- STN+ / STN− — super-twisted nematic in positive and negative modes for higher contrast
- FSTN — film-compensated STN with sharper viewing angle and color neutrality
- FFSTN — filtered FSTN for black-on-white legibility in graphic modules
- CSTN — color STN for low-power dot-matrix applications
- HTN — high-twist nematic at intermediate STN performance
Vertical-alignment LCD (patented)
- PMVA — Passive Matrix Vertical Alignment; true-black background at 1/64 duty
- FS-PMVA — field-sequential PMVA combining RGB backlight with vertical alignment
- Negative-mode operation with deep blacks for cockpit and automotive use
- Color screen-printing and color backlighting for product differentiation
- Wide viewing cone, sunlight readability, wide temperature range
Active-matrix TFT-LCD
- Sunlight-readable TFT modules up to 1500 nits
- Monochrome TFT and ultra-thin wearable TFT
- Optically Bonded Touch Panel (LOCA) integration
- LVDS, MIPI, RGB, SPI, USB and I2C interfaces
- Capacitive and resistive touch options including gloved-operation tuning
- TFT development board with preloaded micro-SD for evaluation
Character & graphic modules
- Character displays from 8×1 through 40×4 columns; low current, high contrast
- Graphic modules 122×32 through 320×240 in positive or negative modes
- COB (Chip-on-Board), COG (Chip-on-Glass), COF (Chip-on-Film) bonding
- TAB and SMT module assembly for high-mix volume programs
- Standard backlight color options: N, Y/G, W, B, R, G, A, O, RGB
- Use cases: handheld meters, automotive and home audio, games, toys
E-Ink / bi-stable
- Active-matrix and segment E-Ink for ultra-low-power applications
- Sunlight readable with wide viewing cone
- Monochrome B/W, B/W/R, B/W/Y and B/W/R/Y options
- Front-light integration for low-ambient operation
- Standard sizes from 1.54″ through 8.14″ across 14 size families
Reflective color & custom monochrome
- Reflective color LCDs with custom rear polarizers — no backlight required
- Fixed color combinations for segmented and dot-matrix displays
- Custom monochrome with glass-thinning and custom-shaped glass
- Cockpit-grade Dichroic, Heilmeier, FMTN and PWTN technologies
- VFD (Vacuum Fluorescent Display) sourcing and integration
- Custom optical, mechanical, and interface engineering for application-specific designs
Relevant Capabilities
Standard product family ranges
Character module families (PC-series) span 8×1, 8×2, 16×1, 16×2, 16×4, 20×4, 24×2, and 40×4 column-by-line configurations in COB and COG bonding, across STN+/STN−, FSTN+/FSTN−, HTN, and FFSTN display modes. Standard backlight color codes are N (none), Y/G (yellow-green), W (white), B (blue), R (red), G (green), A (amber), O (orange), and RGB.
Graphic module families (PG-series) span 122×32, 128×64, 192×48, 192×64, 240×64, 240×128, 240×160, and 240×320 resolutions in COB and COG bonding across STN+/STN−, FSTN+/FSTN−, and FFSTN modes.
Active-matrix TFT-LCD families (PT-series) span 0.96″ through 15.6″ diagonal in 4-SPI, SPI, SPI+RGB, MCU, MIPI, RGB, 8080, LVDS, and dual-LVDS interfaces, with brightness from 200 to 1500 nits across All, 6:00, and 12:00 viewing-direction options and storage envelopes covering −40 °C to +90 °C.
E-Ink families span 1.54″, 1.64″, 2.13″, 2.36″, 2.66″, 2.7″, 2.9″, 3.0″, 4.2″, 4.37″, 7.3″, 7.5″, and 8.14″ sizes with B/W, B/W/R, B/W/Y, and B/W/R/Y color options; front-light and touch availability vary by family.
Detailed datasheet PDFs by part number are available on request — please use the contact form (preselect Datasheets inquiry) and we will route the relevant family to your engineering team.
Relevant Applications
Technical Specifications
| Deliverables | LCD modules, display head assemblies, integrated display systems, bezel-integrated units, operator-interface assemblies |
|---|---|
| Integration Types | Optical bonding, touchscreen integration, NVIS filtering, display-controller integration, enclosure integration |
| Ruggedization Options | EMI shielding, conformal coating, environmental sealing, vibration resistance, thermal management |
| Environmental Properties | Wide-temperature operation, sunlight-readable configurations, ruggedized environmental performance |
| Form Factors | 3.5” to 15”+ diagonal, custom aspect ratios, panel-mount and chassis-mount configurations |
Standards and Compliance
Referenced standards and compatibility frameworks
- MIL-DTL-7788 - Illuminated Panel Integration
- MIL-STD-810 - Environmental Engineering Considerations and Laboratory Testing
- DO-160 - Environmental Conditions and Test Procedures for Airborne Equipment
